GML-BAO 5--188 fixture
Product features
Single-sided bags, single-sided zipper bags, double-sided bags, double-sided zipper bags, clear zipper bags, flap bags, curved bags, trapezoidal bags, parallelogram bags, etc.
Application field
Men's pants back pocket, and pockets within 170mm.
Fixture parameters
| Fixture specifications | 188mm |
| Max available opening | 170mm |
| Blowing function | Standard |
| Air suction function | Optional |
| Scroll up function | Standard |
| Fixture direction | Horizontal |
| Fixture function | Multi-functional · Manual and automatic |
| Safety | Never pinch your fingers |
| Work efficiency | 3-4 pockets can be opened in one minute |
Specifications
| Brand | GML | ||
| Model | GML Leopard-5 | Line drawing method | Spindle |
| Style | Mitsubishi model | Sewing needle | DPX17 |
| Sewing range | 35x20cm | Voltage | 220V |
| Laser range | 24x20cm | Power | 850W |
| Laser head | Left side, lift-type | Cooling | Antifreeze/Purified Water |
| Laser power | 100W | Spare parts | All standardized |
| Laser lifespan | 10000H | Guide rail | Widen and enlarge |
| Operating system | Foolish type | Aircraft frame | Widen and enlarge |
| Create an image | One-click generation | Exhaust pipe | 3M |
| Foot pressure increase | Pneumatic | Footboard | 2个parts |
| Scanner | Standard | Positioning light | 2个parts |
| Broken line detection | Standard | Repair rate | Extremely Low |
| Pressure protection | Standard | NW | 200kg(about) |
| Emergency stop switch | Standard | GW | 300kg(about) |
| Laser head anti-collision | Standard | Machine size | 1520x1080x1250mm |
| Work Light | Standard | Packaging size | 1540x1100x1380mm |
